Replace BEKO FHP420X1 compressor filter element

Replacing the BEKO FHP420X1 compressor filter element, high-precision filter felt filter material is used, with built-in ultra-fine fiber glass fiber filter material significantly improving the filtration accuracy of the filter element. The filter element uses stainless steel or aluminum end caps to avoid secondary pollution caused by carbon steel end caps. The filter element is made of hydrophobic and oleophobic fiber material and a highly breathable skeleton, with an initial pressure drop of l


Basic Barameters

Brand: HYFILTRATE

Model: FHP420X1 T34128

Filtration accuracy: 0.01-5

Country of origin: China

Filter media: air, oil

Filter element type: Air compressor precision filter element

Length: 200mm

Replacing the BEKO FHP420X1 compressor Filter Element, high-precision filter felt filter material is used, with built-in ultra-fine fiber glass fiber filter material significantly improving the filtration accuracy of the filter element. The filter element uses stainless steel or aluminum end caps to avoid secondary pollution caused by carbon steel end caps. The filter element is made of hydrophobic and oleophobic fiber material and a highly breathable skeleton, with an initial pressure drop of less than 0.015MPa and a gradual increase in operating resistance over time (≤ 0.005MPa/100 hours), making it suitable for long-term high load conditions.


FHP420X1 precision filter adopts a multi-layer composite structure, which can effectively intercept solid particles and liquid particles above 0.01 μ m, with a filtration accuracy of up to 0.01 μ m, ensuring the purity of compressed air.

Filter cartridges are usually composed of multiple layers of filtering materials with different functions, including hydrophobic and oleophobic fibers, fine opening sponges, metal skeletons, etc. Its internal design combines interception, inertia, gravity, diffusion, and adsorption effects to effectively remove water vapor, oil mist, dust, and chemical odors.


Technical Parameter

Model: FHP420X1

Outer diameter: 60mm

Height: 200mm

Filter material: Glass fiber

Weight: 0.7kg

Delivery time: 7 days

Skeleton: Stainless steel

End cap: stainless steel

Filter media: air, oil mist, oil fluid


Industry Application
  • Application of filter element
    Application of filter element
  • Filter element for chemical in
    Filter element for chemical in
  • Filter element for steel works
    Filter element for steel works
